Item number: 0101944
10 Variants
Suction cup B110-2 Nitrile-PVC with filter
Several short bellows cups in one lifting device can handle objects with height differences and varying shapes. The bellows also provide a slight lifting moveme...
Read more
Login or create account to access all our content and features!
Variants
0101896
0101897
0101898
0101902
0101903
0101904
0101944
0101945
3250049S
3250049P
Features
- Suitable for level adjustment. Several short bellows in one lifting device can handle objects with height differences and varying shapes, for example embossed or corrugated plates.
- Lifting movement to separate small and thin objects.
- Only lightweight objects should be handled when the lifting force is parallel to the surface of the object, in order to achieve good precision and safe lifting movement.
Logistics
Packaging
General
Material
Nitrile-PVC (NPV)
Characteristics
Dry sheet metal , Plastic injection molded parts
Suction cup model
B
Volume
310 cm³
Weight, min.
120 g
Fitting
Fitting option
None
Fitting size
None
Fitting style
None
Fitting type
None
Dimension
Height
54.3 mm
Outer diameter, actuated
130.6 mm
Outer diameter, min.
112 mm
Performance - lifting forces
B110
20 -kPa
137 N
0 N
60 -kPa
343 N
0 N
90 -kPa
461 N
0 N
Material
Name
Nitrile-PVC (NPV)
Colour
Black
Temperature
0 - 90 °C
Hardness
50 °Shore A
Material resistance
Alcohol
Concentrated acids
Ethanol
n/a
Hydrolysis
Methanol
n/a
Oil
Oxidation
Petrol
Wear resistance
