Item number: 0213346
8 Variants
GZ20-AS50-41-41 Sprue/part plier with long jaws
Login or create account to access all our content and features!
Variants
0213345
0213346
0213347
0213348
0213349
0213350
0213351
0213352
Features
- Movement of the jaws by two pistons.
- No inside recuperating spring, therefore no loss of power.
- A wide range of jaws which can be combined among each other.
- Mounting diameter D = 20 mm or M17 x 1
- 100 % compatible with common products.
- All components are anodized and offer excellent gliding properties as well as the best possible wearing protection.
- Sensor with 2m cable (version -90 / -91).
- Sensor with 0.3 m cable and M8 connector (version -95).
- Easy jaw change by loosening of the safety caps.
Dimensions DWG
Diameter
20 mm
Diameter
M17x1
Height
162 mm
Height
97 mm
Height
97 mm
Height
19 mm
Length
35 mm
Length
48 mm
Length
62 mm
Width
25 mm
Width
4 mm
Width
4 mm
Dimensional drawings
