Item number: 0102651
6 Variants

Vacuum pump MINI L14, conn. Z, NBR seals

COAX® is an advanced solution for creating vacuum with compressed air. Based on Piab’s multistage technology, COAX® cartridges are smaller, more efficient and m...
Read more
Login or create account to access all our content and features!

Select variant

  • 0102651
  • 0102743
  • 0102831
  • 0102832
  • 0102843
  • 0103055

Features

  • Large vacuum flows
  • Small size and low weight
  • Good for handling porous materials or if leakage is present
  • Available with connection plate in aluminium (B1) and composite PA (B, C)

General

Material
Ethylene Propylene (EPDM) , Nitrile (NBR) , PA , POM , SS , Viton®
Noise level
57 - 68 dBA
Temperature
-20 - 80 °C
Weight, min.
13 g

Performance

Feed pressure, max.
0.7 MPa
Feed pressureAir consumptionVacuum flow (Nl/s) at different vacuum levels (-kPa)Max vacuum
MPaNl/s0102030405060708090-kPa
0.60.981.510.570.450.390.320.240.130075
