Item no: S.PAXB
Suction cup PAXB family
Piab Automotive X-tra Bellows (PAXB), specially designed friction cup with multi bellows for dry and oily metal sheets in automotive body shop applications where great level compensation is needed. The PAXB design is suitable for flat as well as uneven/curved surfaces with an internal friction pattern for handling oily surfaces.
Read more
Configure
This is a configurable product. Please use the configurator to customize the item to your needs and see updated price and availability there.
Features
- Automotive suction cup – addressing body shop segment and supporting industry standard in those applications.
- Made of black Nitril-PVC, 60 shore (A), silicone free. A durable material giving a cost effective good performing cup for automotive applications.
- Round, multi- bellow suction cup for dynamic handling of very uneven or curved workpiece surfaces.
- Very good stability and resistance to horizontal forces compared to similar cups.
- Very high stroke, good for great level compensation.
- Handling of thin sheets without deformation or denting objects.
- For dry as well as oily sheets.
- Friction pattern on the lip prevents sheets from slipping.
- Wide sealing surface for better sealing over dust and debris.
- Low required vacuum level for actuation, gives good vacuum reserve for the lift itself.
- Fitting options: cup has a molded-in aluminum insert, so either use your own fitting solution or use one of the nine (9) fitting options from Piab.
-
Industries
Automotive
- Loading and unloading metal sheets
- De-stacking
- Press-transfer
- End of line racking
- Underbody, engine & trunk compartment assembly
- Bodysides & framing
- Closures - hemming stations – inner & outer assembly
- Auto-racking unload & assembly
- Kitting picking of parts
- Door on / off ergo tools
- Gas tank assembly and installation
Metal sheets
Wood
-
Specifications
General
Suction cup shapeMultibellowsSuction cup designRoundCharacteristicsFrictionPattern, PWISFreeMaterialNitrile-PVC (NPV)Outer diameter, min.32;42;52;62;88 mmMaterial
NameColourBlackTemperature0 - 90 °CHardness60 °Shore AAlcohol++Concentrated acids+Ethanoln/aHydrolysis++Methanoln/aOil+++Oxidation++Petrol+++Wear resistance+++Weather and ozone++ -
