Item number: 9914237
3 Variants
Suction cup F33 Silicone FCM, G1/4" male
The material used is food grade silicone material. It is free from colour pigments, approved by FDA (FDA 21 CFR 177.2600. ) and meets EU's regulation EU 1935/20...
Read more
Login or create account to access all our content and features!
Variants
0200328
9914237
9914252
Features
- Designed for opening bags in bag filling stations.
- Also suitable to handle thin and sensitive sheets, such as paper and plastic films.
- The thin, conformable lip and clever cleat pattern prevent sensitive object/sheet to get sucked in and damaged while giving enhanced lifting force.
- FDA 21 CFR 177.2600 & EU 1935/2004 approved silicone material.
Food & beverage
Packaging
- Bag and pouch opening
- Direct food contact
General
Material
Silicone (SIL)
Characteristics
Bag opening/thin paper - slip sheets/film , Food contact materials (FDA & EU), non-detectable
Suction cup model
F
Volume
2.1 cm³
Weight, min.
5.4 g
Fitting
Fitting option
None
Fitting size
1/4"
Fitting style
Male
Fitting type
G-thread
Dimension
Height
38.5 mm
Outer diameter, actuated
33.8 mm
Outer diameter, min.
32.6 mm
Performance - lifting forces
F33 FDA
20 -kPa
16 N
13.5 N
60 -kPa
38 N
32.5 N
90 -kPa
49 N
41.5 N
Material
Name
Silicone (SIL FDA) 50° Shore
Colour
Blue
Temperature
-40 - 200 °C
Hardness
50 °Shore A
Material resistance
Alcohol
Concentrated acids
Ethanol
n/a
Hydrolysis
Methanol
n/a
Oil
Oxidation
Petrol
Wear resistance
